Jazzy® Passport w/ 18 AH Lithium Battery
DESCRIPTION
It’s the trip of a lifetime! Feel the anticipation as you wait for your flight in the comfort and style of your Jazzy® Passport. This compact power chair has plenty of storage and folds in just a few steps to make airport check-in effortless. When your plane touches down at your destination, you are ready to experience the adventures that await you!
Setting the scene with the ultimate folding electric wheelchair.
Your Jazzy® Passport adventure starts when you do, even if that means an early morning flight or train ride. Navigate terminals with ease using convenient features that only a folding electric wheelchair can provide. Never be late to the gate!
These moments in a quiet terminal halfway between origin and destination make traveling memorable. You want to soak it all up, and your Jazzy Passport power chair takes you there.
Have Jazzy Passport, will travel
Jet set with confidence in the versatile design of your Jazzy Passport. It’s extremely portable and folds neatly to be stowed away in a car trunk or, yes, on a plane. Folded, its dimensions are a compact 31" x 23.5" x 16". It weighs just about 60 pounds depending on battery size.
The Jazzy Passport power chair has a weight capacity of 250 pounds and a 3.6 mph maximum speed. Depending on your package choice, you can count on up to 11 miles on a single charge.
Your journey starts when you do
Take a break and savor the moments on your trip with a drink in the cup holder and a warm chocolate croissant. You can comfortably sit by the window and watch the lights of the next arriving flight.
Several of the great benefits of the Jazzy® Passport is the 3-inch ground clearance and the folded dimensions (31" H x 23.5" W x 16" D) to easily fit into several types of vehicles. The lithium-ion travel battery makes travel safe as well as portable, so you can transport your portable electric wheelchair on a plane! With an airline-approved lithium-ion air safe travel battery**, the sky is the limit for all of your travels! A dual braking system provides extra security and safety. And don’t forget the storage! Keep all your belongings within reach with the under-seat storage and back seat pocket.
*Pride® FDA Class II Medical Devices are designed to aid individuals with mobility impairments
**Note: Transport of this item on commercial aircraft is subject to federal regulations and airline policy. Please consult your airline prior to your flight to ensure your Jazzy® Passport and its lithium ion battery are permitted.
- 250 lbs. weight capacity
- Up to 3.6 mph maximum speed
- 24.25" turning radius
- Up to 8.6 miles (220 lbs.); up to 7.9 miles (250 lbs.)
- Back seat pocket for extra storage while on-the-go
- Easy-access free-wheel lever
- A compact and lightweight design makes traveling a breeze
- Folds in just a few simple steps for effortless transport
- Includes convenient, under seat mesh storage bag, mesh cup holder and 40” lap belt
- Large foot platform to accommodate the user’s comfort
- Specialty foam seat design for extreme comfort
- Available with your a 10.4 AH or 18 AH lithium-ion air safe travel battery** (**Check with your airline before flying.)
- K0899 Power Mobility Device, not coded by DME PDAC or does not meet criteria
| CATEGORY | SPECIFICATION |
|---|---|
| Model |
Jazzy® Passport |
| Weight Capacity | 250 lbs. |
| Turning Radius1 | 24.25" |
| Maximum Speed1 | Up to 3.6 mph |
| Ground Clearance3 | 3" at motor |
| Overall Length3 | 40" (with footplate) |
| Overall Width3 | 23.5" |
| Seat-to-Ground Height | 19" |
| Seat-to-Foot Platform Height | 14.5" (no adjustment) |
| Casters | 8" solid |
| Rear Wheels | 1.75" anti-tips |
| Drive Wheels | 11.25" Perforated |
| Suspension | Limited |
| Range per Charge1,2 | Up to 5 Miles (220 lbs.) (10.4AH) Up to 8.6 miles (220 lbs.) (18AH) Up to 4.6 miles (250 lbs.) (10.4AH) Up to 7.9 Miles (250 lbs.) (18AH) |
| Total Weight Without Batteries3,5 | 59.8 lbs. |
| Heaviest Piece When Disassembled3 | N/A |
| Standard Seating | Material: Black, Foam Dimensions: 17.5" x 16.5" |
| Drivetrain | Two-motor rear-wheel drive |
| Standard Electronics | 50 amp PG VSI |
| HCPCS Codes | K0899 Power Mobility Device, not coded by DME PDAC or does not meet criteria |
| Dual Braking System | Regenerative and electromechanical |
| Battery Requirements3 | 25.2V 18 Ah Lithium ion or (1) 25.2 V 10.4 Ah Lithium-ion (travel battery) |
| Battery Weight4 | 7.6 lbs. (18 Ah) 5.2 (10.4Ah, travel battery) |
| Battery Charger | 2-amp, off-board |
| Weight of Heaviest Piece | 59.8 lbs. (unit does not disassemble) |
| Warranty | 5-year limited on frame; 13-month limited on electronics; 13-month on drive motors 13-month limited on batteries. |
| Notes: 1 Varies with user weight, terrain type, battery amp-hour (AH), battery charge, battery condition, and tire condition. This specification can be subject to a variance of (+ or -) 10%. 2 Tested in accordance with ANSI/RESNA, MC Vol2, Section 4 & ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Test conducted at maximum weight capacity. 3 Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+ or -) 3%. 4 Battery weight may vary based on battery manufacturer. 5 Includes standard seat weight. |
|
| All specifications subject to change without notice. The information contained herein is correct at the time of publication; we reserve the right to alter specifications without prior notice. Speed and range vary with user weight, terrain type, battery charge, battery condition and tire pressure. Due to manufacturing tolerances and continual product improvement, length, width, turning radius and ground clearance can be subject to variance of + or – 3 %. Dimensions listed are for power base only. Overall measurements will vary based on seating and accessory selections. | |
|
Note: Transport of this item on commercial aircraft is subject to federal regulations and airline policy. Please consult your airline prior to your flight to ensure your Jazzy® Passport and its lithium ion battery are permitted. |
|
